Electrical Capacity
Power: 5A at 125V AC, 3A at 250V AC and 3A at 30V DC;
Other Ratings
Contact resistance: 10 milliohms
Insulation resistance: 200 megohms minimum at 500V DC
Dielectric strength: 1,000V AC minimum between contacts at least one minute;
Between contacts and housing at least one minute minimum 1,500V AC
Mechanical life: 30,000 operations minimum
Electrical life: 10,000 operations minimum
Nominal Operating Force: For Rocker 9.94N; the handle 4.41N
Swing angle: 24 for On-None- (On) circuit; 28 for other circuits
Materials & Finishes
Housing: stainless steel
Movable Contacts: Silver alloy
Stationary Contacts: Silver
Housing: phenolic resin
Public Terminals: silver-plated copper
End terminal: silver-plated copper
Lamp Terminals: nickel-plated phosphor bronze
Environmental Data
Operating temperature range: -10 C to + 50 C (+ 14 F to + 122 F)
Humidity: 96 hours Internal 40 C (104 F), the humidity of 90% to 95%
Vibration: 1.5mm peak - peak amplitude of the traverse 10 ~ 55Hz frequency range, returning in 1 minute; 3 right angled directions 2 hours
Shock: 50G (490m / s2) acceleration (at right angles to the direction of the three tests, 3 shocks in each direction)
Installation
Cap Installation Force: Rocker 9.80N (2.2 lbf); handle 19.61N (4.4 lbf)
Welding time and temperature: Manual Soldering: See Appendix schematic diagram A.
Standards and Certification
UL certification: UL File No. E44145
All models are certified condition at 125V AC 5A and 3A at 250V AC.
To order UL mark on switch, finally add "/ U" in the part number.
To order have CULus marked switch, and finally add the "/ CUL" in the part number
