WiFi Web Sever Shield Kit with Arduino 2560 + ESP8266 Serial Board DIY Development Extension | Игрушки и хобби

    ESP8266-Based Serial WiFi Shield for Arduino is designed and developed by Shenzhen Doctors of Intelligence & Technology (SZDOIT). The shield is designed based on esp8266 by Espressif Systems, pin-compatible with  UNO/ DevBorad.

Web Sever Configure Mode

and then you can find the WiFi signal from Arduino shield.

Features:

• The module shield can be used as an independent ESP8266 development board. for instance, downloading the official AT commands firmware, NodeMCU open source firmware can be used;

• WebServer is developed to configure WiFi parameters and serial port parameters;

• Serial data is transported to WiFi device transparently, and vice versa.  Arduino program does not need any configuration;

• Dual DIP switches is used for serial ports so that this module shield can be used alone as an Arduino Uno expansion board, and also be used as ESP8266 expansion board;

• Shield is pin-compatible with other control board. A voltage converter chip is used to deal with 3.3V (Esp8266) and 5V (Arduino);

• WiFi module is industrial-grade chips ESP8266, which is ESP-12E with metal shield, strong anti-interference ability;

• The module shield also can be used as stand-alone expansion board for Arduino Uno.

Parameters:

• 802.11 b / g / n wireless standards;

• STA / AP modes support ;

• TCP / IP protocol stack, One socket;

• Supports standard TCP / UDP Server and Client;

• Supports serial port baud rate configuration:

• 1200/2400/4800/9600/19200/38400/57600/74800/115200 bps;

• Supports serial data bits: 5/6/7/8 bits;

• Supports serial parity: none;

• Supports serial stop bits: 1/2 bit;

• Pin-compatible with Arduino UNO, Mega;

• Arduino Pinout 2/3/4/5/6/7/8/9/10/11/12/13;

• ESP8266 GPIO Pinout 0/2/4/5/9/10/12/13/14/15/16 / ADC / EN / UART TX / UART RX;

• KEY button: modes configuration;

• Dual-Ports DIP switches: switching Arduino and ESP8266;

• WiFi operation current: continuous transmission operation: ≈70mA (200mA MAX), idle mode:<200ua;< span="">

• Serial WiFi transmission rate: 110-460800bps;

• Temperature: -40 ~ + 125 deg;

• Humidity: 10%-90% non-condensing;

• Weight: about 20g;

Package Included:

• ESP8266 WiFi shield: 1pcs

• 2560: 1pcs

• cable: 1pcs
